CADLink Bidirectional CAD Acumatica BOM Sync Tool

Create Item Master and BOM records in your Acumatica Cloud ERP that are identical to your CAD models with the click of a button!

The direct integration makes manual data entry and clerical errors a thing of the past. Connect from your CAD system integrating bi-directionally with Acumatica.

With data validation that helps you check for user errors, CADLink will make sure that you have synchronized and accurate information. Let CADLink do the work for you, making sure that the records going into Acumatica are accurate and complete!

You can also find CADLink in the Acumatica Marketplace with some additional resources.

QBuild Quality

You know you are getting the right solution when you work with QBuild Software! QBuild has over a decade of experience and expertise in CAD – ERP integration. QBuild was chosen as an integration partner.

Acumatica CADLink features

Acumatica CADLink BOM Interface

Color Coded Changes

Benefit from a color coding system inside your BOM grid to quickly see results and required tasks to save into Acumatica.

Green fields   represent new parts that will be created in your Acumatica Item Master.
Yellow fields   highlight data discrepancy between CAD and Acumatica such as description or BOM qty.
Gray fields   represent parts to be removed from your Acumatica BOM.

Powerful Visual Interface

Engineers are visual people. That is why Acumatica CADLink offers a highly visual and intuitive interface to display BOM changes and data discrepancies.

Eliminate Duplicate Manual Data Entries

Acumatica CADLink’s single-step process eliminates duplicate manual data entries of engineering data in your Acumatica ERP.

Powerful Searches

Perform a live search in your Acumatica Item Master and insert raw materials and non CAD modeled items to your  bill of materials. Create a complete BOM for your shop floor; not just what your engineers modeled.

Small Footprint

No dedicated IT department? No problem! CADLink is a client-based application with a minute hardware and software requirements. CADLink installation requires no additional database or server components, keeping a footprint as light as your work time will be.

1 Click Summary Report

Generating an Excel BOM export and a change summary PDF report for your records is easier than ever! One click is all you need to meet your documentation requirements.

Increase the speed of data flow from sales to engineering, purchasing, and production

Streamlining the entire product development process by integrating your CAD systems (SOLIDWORKS, AutoCAD, CREO, Altium, CATIA, etc.) and your Acumatica solution gives you the edge in the competitive market. CADLink will free up your engineering staff to do more engineering and reduce your engineering costs. The less time they spend inputting data across multiple platforms, the more time they can invest on projects and designs.

Benefit from an accurate and up-to-date data version and improve your production throughput

In today’s fast paced industry, keeping your Acumatica engineering data accurate and synchronized with your engineering drawings and models quickly and accurately is critical in gaining competitive edge. With CADLink, you will see significant improvements in time to market, on-time shipments, and accuracy of Acumatica engineering data with reductions in engineering cost, scrapped parts, and shop floor confusions.

acumatica-logo-dark

Direct Integration to Acumatica, your Cloud ERP!

Direct CAD Integration

Your engineers live and breathe inside their CAD system and they love it! So let’s keep it that way and let CADLink connect your CAD system to Acumatica.

Real-time, direct, two-way link between your CAD and Acumatica allows your engineers to compare, create, and update Acumatica Item Master and BOM records right from the comfort of the CAD system of your choice. An intuitive interface displays indented multi-level BOM and thumbnail preview image of the CAD part so you know what you are looking at. Integrations for all the leading mechanical and electrical CAD, as well as woodworking and structural CAD packages are available to you.

Direct ERP Integration

Set default value or assign critical Acumatica fields such as Inventory UOM, Part Class, Part Group, etc. CADLink lets you access Acumatica data to see ERP drop-down fields and search Item Master to insert raw materials and non CAD modeled items to your BOM.

Live Data Comparison

Take control of your changes. The live comparison feature lets you visually review BOM changes before committing to save. The changes and discrepancies between the two systems are colour coded to let you know what will be affected in both systems!

Bi-Directional Connection

A key to any successful relationship is two-way communication. CAD – ERP integration is no exception to this! Acumatica CADLink can write back to your CAD model properties to keep your CAD engineering data in sync with your Acumatica data.

Always Compatible

Our partnerships with Acumatica and your CAD provider enable us to always keep your CADLink current, working seamlessly and with no down-times during version upgrades. QBuild has the resources to develop a custom solution to satisfy your needs while tightly following your company standards.
